As a simple way to realize network surveillance, the IP camera can directly
connect to a network by a network cable. Images are compressed in H.264 compress
format before pass the network cable to the other side. The IP camera comes
with a built-in web server as the nature of the network device.

HIKVISION OEM Product



Model Code 2IP892PF



Colour Type Colour

Chip Inch Size 1/3

Resolution 480 TVL

Sensitivity Lux 0.1 /F1.2

Auto Iris Yes

Lens Mount C/CS

Motion Activated Yes

Picture Elements HxV 704 x 576

Network Properties Image Frame Rate: 25fps

Interface: RJ45 10M/100M Ethernet Port

Network Protocols: TCP/IP, HTTP, DHCP, DNS, RTP/ RTCP, PPPoE

Electronic Shutter Range 1/50 ~ 1/100,000

S/ N (Signal/ Noise) Ratio dB 48

Signal Mode PAL, NTSC

Compression Type H.264

Electrical Specifications Power Consumption: 4 W

Voltage: 12 VDC, PoE

Physical Specifications Dimensions mm: 63 x 59 x 114

Weight g: 650

Operating Temperature: -10°C ~ +60°C



The IP camera needs these accessories at extra cost.

Lens

Power Supply 12V DC
